Chips in the category 'VIDEO'

nr name description manufacturer
Cobra XGA Graphics controller Chip IBM*
VGA Several VGA-Chipsets: Regs many
0220 MK0220 16 pin for portable video CD players using C-Cube's CL480 MicroClock*
0491 KDA0491 triple* 256*8 RAMDAC 66-110MHz Samsung
1001 AML1001 MPEG-1 audio/video decoder Amlogic*
1002 AML1002 Enhanced MPEG-1 audio/video decoder with karaoke Amlogic*
10823 XR10823 8mm VTR Automatic Tracking Filter Exar (obsolete)
1203 LM1203 RGB video amp* 70MHz NS
1203 LT1203 2:1 video mux* LT
1205 LT1205 dual* 2:1 video LT
1330 MC1330 low level video detector Motorola
1330 MC1330AP AM*/Video synchronous detector pos. and neg. output, for video descrambling etc. order from Barend
1378 MC1378p synchroniser color video o/lay Motorola
1410 MK1410 8 pin package with NTSC*/PAL* frequencies. MK1410 has power down for notebooks. Ideal for AD722 MicroClock*
1411 MK1411 8 pin package with NTSC*/PAL* frequencies. MK1410 has power down for notebooks. Ideal for AD722 MicroClock*
1427 MK1427 8 pin low cost for CL450 and other MPEG I decoders MicroClock*
1452 MK1452 16 pin for AuraVision MPEG playback board MicroClock*
1453 MK1453 general MPEG, Oak reference design. In 16 pin narrow SOIC MicroClock*
1455 MK1455 8x8 /Siemens or Philips videoconferencing reference platform. In 16 pin narrow SOIC MicroClock*
1456 MK1456 8x8 /Siemens or Philips videoconferencing reference platform. In 16 pin narrow SOIC MicroClock*
153108 Color Palette Hitachi*
153109 Color Palette Hitachi*
153110 Color Palette Hitachi*
153119 Color Palette Hitachi*
153129 Color Palette Hitachi*
1573 MK1573 16 pin GenClock for genlock. Generates video frequency clocks synchronized to NTSC*/PAL* HSYNC MicroClock*
1604 MK1604 16 pin, low cost, for videoCD. For C-Cube 480, 482, 484, and Winbond reference designs MicroClock*
1605 MK1605 16 pin, low cost, for videoCD. For C-Cube 480, 482, 484, and Winbond reference designs MicroClock*
1630 MK1630 16 pin for desktop videoCD. Has NTSC*/PAL*, 40.0 or 40.5, 27, 16.9344, 13.5MHz, and selectable microcontroller clock MicroClock*
1631 MK1631 16 pin for desktop videoCD. Has NTSC*/PAL*, 40.0 or 40.5, 27, 16.9344, 13.5MHz, and selectable microcontroller clock MicroClock*
170 Color look-up table Inmos
1881 LM1881 video sync* separator NS
1890 CA1890E TV video/audio RF modulator RCA
19680 TGU19680 Video controller Trident
20311 High performance RAMDAC AT&T
20511 High performance RAMDAC AT&T
21505 High performance RAMDAC AT&T
215121 215GT1NA21 3D RANGE Video ATI
236 A236 Parallel Video DSP chip, Data OMDI*
2440 2-channel Multiplexed Video Amplifier NS
2453 LZ2453 811x507 color NTSC* imager Sharp $80
2500 SAA2500 ISO/MPEG layer 1,2 audio source decoder Philips
2501 SAA2501 Improved ISO/MPEG audio source decoder Philips
2510 SAA2510 Video-CD MPEG-Audio/Video decoder circuit Philips
2712 MK2712 8 pin package with NTSC*/PAL* frequencies for video encoders and decoders. Has 14.3, 17.7, 28.6, 35.5MHz MicroClock*
2742 MK2742 general set-top box/MPEG clock with multiple outputs, zero ppm audio. In 16 pin narrow SOIC MicroClock*
2743 MK2743 provides all necessary clocks for C-Cube 60 and 66.66 MHz MPEG encoders. In 16 pin narrow SOIC MicroClock*
2744 MK2744 general set-top box/MPEG clock with multiple outputs, zero-ppm-audio. Also Zoran AC-3. In 16 pin narrow SOIC MicroClock*
2751 MK2751 MPEG with zero ppm audio, AuraVision and C-Cube support. In 16 pin narrow SOIC MicroClock*
2752 MK2752 for ESS MPEG. Has 27, 13.5, 33MHz and selectable audio clock. In 16 pin narrow SOIC MicroClock*
2753 MK2753 for ESS MPEG. Has 27, 13.5, 33MHz and selectable audio clock. In 16 pin narrow SOIC MicroClock*
327432 MP3274(32) Fault Protected 32 Channel 12-Bit Data Acquisition Subsystem Exar
327516 MP3275(16) Fault Protected 16 Channel 12-Bit Data Acquisition Subsystem Exar
327616 MP3276(16) Fault Protected 16 Channel Exar
328256 MT32C8256 256k*8 VRAM* EDO Micron
3321 M3321 MPEG-II Audio/Video Decoder ALi*
34070 tms34070nl video 36mhz palette TI
3504 TDA3504 PAL*/SECAM* Video control combination DIL20 Philips
3505 TDA3505 PAL*/SECAM* video control combination DIL28 Philips
3506 TDA3506 PAL*/SECAM* video control combination DIL28 Philips
3507 MAS3507D MPEG 1/2 Layer 2/3 decoder, PLCC44 Micronas
3507 MAS3507D MPEG 1/2 Layer 2/3 decoder, PQPF44 Micronas
3508 TDA3508 Video control combination circuit DIL28 Philips
3926 NT3926 TFT display controller Novatek
3927 NT3927 TFT display controller Novatek
3950 NT3950 TFT display controller Novatek
3960 NT3960 TFT display controller Novatek
41264 D41264 64k*4 VRAM* NEC
422 AL422 3M-bit Frame buffer Averlogic*
4225616 MT42C256K16A1 256k*16 VRAM* EDO Micron
42264 D42264 64k*4 VRAM* CMOS* NEC
42273 D42273 256k*4 VRAM* NEC
42274 D42274 256k*4 VRAM* flash write NEC
42275 D42275 128k*8 VRAM* NEC
424256 MT42C4256 256k*4 VRAM* 512*4 SAM Micron
435 MAX435 250MHz Wideband Differential In/Out Transconductance Amplifier. Maxim*
436 MAX436 250MHz Wideband Transconductance Amplifier. Maxim*
4411 XRD4411_ 12 Single and Dual* High Speed CCD* Analog Signal Processors Exar
4417 XRD4417 3.3V CMOS* Linear CCD* Signal Processor with 10-Bit ADC and Serial Interface Exar
44171 XRD4417(1) 3.3V CMOS* Linear CCD* Signal Processor with 10-Bit ADC and Serial Interface Exar
4423 XRD4423 Triple* High Speed CCD* Analog Signal Processor Exar
4433 XRD4433 Analog-to-Digital Converter with Digitally Controlled References Exar
4460 XRD4460 CCD* Image Digitzers with CDS Exar
4460 XRD4460A CCD* Image Digitzers with CDS Exar
4461 XRD4461 CCD* Image Digitizers with Programmable Gain and Stand-by Mode Exar
452 MAX452 Video amp* order from Barend
453 Bt453 triple* 8 bit RAMDAC Brooktree
458 MAX458 8x4, 100MHz Video Crosspoint switch with Output Buffers Maxim*
459 MAX459 8x4, 100MHz Video Crosspoint switch with Output Buffers (AV = 2V/V) Maxim*
463 MAX463 100MHz Triple* RGB Video switch with Buffer Maxim*
464 MAX464 100MHz Quad* RGB Video switch with Buffer Maxim*
465 MAX465 100MHz Triple* RGB Video switch with Av = 2V/V Buffer Maxim*
466 MAX466 100MHz Quad* RGB Video switch with AV = 2V/V Buffer Maxim*
467 MAX467 100MHz Triple* (RGB) Video Buffer Maxim*
468 MAX468 100MHz Quad* Video Buffer Maxim*
469 MAX469 100MHz Triple* (RGB) Video Buffer (AV = 2V/V) Maxim*
470 MAX470 100MHz Quad* Video Buffer (AV = 2V/V) Maxim*
476 ADV476 256*18 CMOS* Color Palette VGA-compatible RAM-DAC, Data, AD
4780 TDA4780 Video control with gamma correction DIL28 Philips
4820 TDA4820 Video sync* separation circuit Philips
482234 D482234 VRAM* fast page NEC
482235 D482235 256k*8 VRAM* EDO NEC
5027 CRT5027 CRT* display controller SMC
5037 CRT5037 CRT* display controller SMC, Mostek:MK3807, TI:TMS9927
5047 CRT5047 CRT* display controller SMC
5057 CRT5057 CRT* display controller SMC
514 RGB514 RGB Series Palette DAC, Data IBM*
514260 HY514260B Video RAM Hyundai
524 RGB524 RGB Series Palette DAC, Data IBM*
525 RGB525 RGB Series Palette DAC, Data IBM*
526 RGB526 RGB Series Palette DAC, Data IBM*
528 RGB528 RGB Series Palette DAC, Data IBM*
530 RGB530 RGB Series Palette DAC, Data IBM*
5592 NE5592 Dual* video/RF amp* order from Barend
5592 NE5592 dual* 110 MHz video amplifier DIL14 Philips
561 RGB561 RGB Series Palette DAC, Data IBM*
5701 M5701 DVD-ROM controller ALi*
5703 M5703 DVD RF Signal Processing Chip ALi*
592 NE592 120 MHz video amplifier DIL8/14, CERDIP14 Philips
592 NE592-14 same, DIL14 order from Barend
592 NE592-8 Pincomp. 733 video/HF DIP8 order from Barend
592 NE592-SO8 same, SMD order from Barend
6101 TDA6101BQ 8 MHz video output amplifier DBS9MPF Philips
6101 TDA6101Q 8 MHz video output amplifier DBS9MP Philips
6101 TEA6101 Antenna diversity circuit DIL18 Philips
6103 TDA6103Q triple* video output amplifier DBS9MP Philips
6111 TDA6111Q 16 MHz video output amplifier DBS9MP Philips
612 NE612A Double-balanced mixer and oscillator DIL8 Philips
612 SA612A Double-balanced mixer and oscillator DIL8 Philips
6120 TDA6120Q 30 MHz video output amplifier DBS9MP Philips
622424 MS622424 triple* 8k*8 colormap 70MHz Mosel $29
624 RGB624 RGB Series Palette DAC, Data IBM*
6345 CRT* controller Hitachi*
63484 Advanced CRT* controller Hitachi*
63486 Graphic Video Attribute controller Hitachi*
63487 Memory Interface Video Attribute controller Hitachi*
6414 XRD64L14 3.3V CMOS* 10-Bit Exar
64144 XRD6414(4) CMOS* 10-Bit 20 MSPS High Speed Analog-to-Digital Converter with 4:1 Input Analog Multiplexer Exar
64188 XRD6418(8) CMOS* 10-Bit Exar
64200 64200 Wingine series, 2M, Linear frame buffer
643 DG643 SPDT video switch, 8 ohm 500 MHz Siliconix
64300 64300 Wingine series, 2M,
64310 64310 Wingine series
64400 Graphic Data Processor Hitachi*
6445 CRT* controller Hitachi*
64460 CRT* controller Plus Hitachi*
65510 F65510 LCD/CRT* controller C&T, is now Intel
65520 F65520 VGA controller 1M D/VRAM* do. Full color. max 1280*1024 16c and 800*600 256 col. C&T, now Intel
65525 F65525 LCD/CRT* controller C&T, now Intel
65530 F65530 VGA controller 1M D/VRAM* do. Full color. max 1280*1024 16c and 800*600 256 col., Supports Local Bus. C&T, now Intel
65535 F65535 LCD/CRT* controller C&T, now Intel
65540 F65540 C&T, now Intel
65545 F65545 C&T, now Intel
6704 RC6704 triple* video amp* Ray
6845 6845 pinout
6845 MC6845 CRT* controller (as in IBM PC Monochrome and CGA screens) Motorola*, UMC
6847 MC6847 CRT* controller (Low cost) Motorola
6862 NT6862 Monitor controller Novatek
7131 SAA7131 MPEG-1 video and audio decoder Philips
7164 SAA7164 Video and enhancement DAC Philips
7165 SAA7165 Video enhancement and D/A processor Philips
7168 SAA7168 Video and graphics digital overlay/mixing Philips
7170 ADV7170 Digital PAL*/NTSC* Video Encoder with 10-Bit SAFF tm and Advanced Power Management, data AD
7171 ADV7171 Digital PAL*/NTSC* Video Encoder with 10-Bit SAFF tm and Advanced Power Management, data AD
7175 ADV7175 Digital Video Encoder, data AD
7175 ADV7175A Digital Video Encoder with Macrovision with Anticopy Circuitry, data AD
7176 ADV7176 Digital Video Encoder, data AD
7176 ADV7176A Integrated Digital Video Encoder, data AD
7177 ADV7177 Integrated Digital CCIR-601 to PAL*/NTSC* Video Encoder, data AD
7178 ADV7178 Integrated Digital CCIR-601 to PAL*/NTSC* Video Encoder, data AD
7181 SAA7181 MPEG-1 video decoder and system demux* Philips
7183 SAA7183 Video encoder with MACROVISION Revision 6 Philips
7185 SAA7185 Video encoder Philips
7186 SAA7186 Digital video scaler Philips
7187 SAA7187 Video encoder Philips
7188 SAA7188A Video encoder with MACROVISION Philips
7197 SAA7197 Clock-signal generator for desktop video DIL20 Philips
7199 SAA7199B Digital video encoder Philips
7220 Graphics display controller NEC, SMC, Intel:82720
72264 MP7226(4) BiCMOS Fixed Quad* Voltage Output Single or Dual* Supply 8-Bit Digital-to-Analog Converter Exar
72288 MP7228(8) BiCMOS Fixed Octal* Voltage Output Single or DualSupply 8-Bit Digital-to-Analog Converter Exar
7281 7281 Color graphics and monochrome adapter (=6845+CharROM for PC) NCR*
7316 LA7316AN VHS color-under chroma processor Sanyo
7326 LA7326 VHS color-under luminence processor Sanyo
733 µA733 Differential video amplifier DIL14 Philips
733 µA733C Differential video amplifier DIL14 Philips
74911 74C911 display controller
74912 74C912 display controller
74917 74C917 display controller
75282 MP7528(2) CMOS* Dual* Buffered Multiplying 8-Bit Digital-to-Analog Converter Exar
75292 MP7529A(2) 15V CMOS* Dual* Buffered Multiplying 8-Bit Digital-to-Analog Converter Exar
75292 MP7529B(2) 5V CMOS* Dual* Buffered Multiplying 8-Bit Digital-to-Analog Converter Exar
76108 MP7610(8) Octal* 14-Bit DAC Array? D/A Converter with Output Amplifier and Serial Data/Address µP Control Logic Exar
76118 MP7611(8) Octal* 14-Bit DAC Array? D/A Converter with Output Amplifier and Parallel Data/Address µP Control Logic Exar
76128 MP7612(8) Octal* 12-Bit DAC Array? D/A Converter with Output Amplifier Exar
76138 MP7613(8) Octal* 12-Bit DAC Array? D/A Converter with Output Amplifier and Parallel Data/Address µP Control Logic Exar
76284 MP7628(4) 5V CMOS* Quad* Multiplying 8-Bit Digital-to-Analog Converter Exar
76418 MP7641(8) 8-Channel Voltage Output 10 MHz Input Bandwidth 8-Bit Multiplying DACs with Serial Digital Port Exar
76434 MP7643(4) 4-Channel Programmable Gain Voltage Output Exar
76518 MP7651(8) 8-Channel Voltage Output 10 MHz Input Bandwidth 8-Bit Multiplying DACs with Serial Digital Data Port and Chip Select Decoder Exar
76524 MP7652(4) 4-Channel Voltage Output 15 MHz Input Bandwidth 8-Bit Multiplying DACs with 3-Wire Serial Digital Port and Independent References Exar
76708 MP7670(8) 8-Channel Voltage Output 5 MHz 4 Quadrant Multiplying Exar
76804 MP7680(4) 5V CMOS* 12-Bit Quad* Double-Buffered Multiplying Digital-to-Analog Converter Exar
8002 CRT8002 VDAC display controller SMC
8021 CRT8021 Video attributes controller SMC
8052 Am8052 Alphanumeric CRT* controller (with 8152) AMD
8150 Am8150 Display Refresh controller AMD
8151 Am8151 Graphics Color Palette (GCP) AMD
8152 Part of CRT* controller chip set (with 8052) AMD
8152 Am8152A Video System controller (VSC) AMD
8153 Video system controller chip set (with 8152) AMD
8153 Am8153A Video System controller (VSC) AMD
8157 Am8157 Video Shift Register (VSR) AMD
8158 Am8158 Video Timing controller (VTC) AMD
8244 8244 Video Display Controller, only known use was (Exclusive contract) Magnavox Odyssey 2 Game Console (1978-1983). Non-US equivalent: Phillips Videopac G7000 system Intel
82450 82c450 VGA controller 1M VRAM* A '453 with VRAM* C&T, now Intel
82451 82c451 VGA controller 256k DRAM max 800*600 16col C&T, now Intel
82452 82c452 VGA controller 1M DRAM max 640*480 256col, 1024*768 16 col C&T, now Intel
82453 82c453 VGA controller 1M DRAM max 800*600 256 col C&T, now Intel
82455 82c455 VGA controller 256k DRAM Flat Panel version C&T, now Intel
82456 82c456 VGA controller 256k DRAM C&T, now Intel
82457 82c457 video card controller Full color. C&T, now Intel
8275 Programmable CRT* controller Intel
8275 i8275 CRTC Intel
8276 i8276 CRTC Intel
8312 Double row buffer for CRT* controller (=9212) UMC
8321 CRT* video attributes controller =9021 UMC
8395 TDA8395 Alignment-free SECAM* decoder DIL16 Philips
8402 32-Bit Parallel EDAC NS
8408 DAC8408 quad* 8 bit MDAC IO* 200ns PMI
8442 TDA8442 I2C interface for colour decoders in DIL16 Philips
8480 TDA8480 RGB gamma-correction processor Philips
8490 TDA8490 SECAM* decoder DIL18 Philips
8500 Raster Graphics Processor (RGP) NS
8510 BitBlt Processing Unit NS
8511 BitBlt Processing Unit NS
8512 Video Clock Generator (VCG) up to 225 MHz NS
8513 Video Clock Generator Slave NS
8515 Video Shift Register - 10k ECL* Outputs NS
8516 Video Shift Register - 100k ECL* Outputs NS
85176 35,50 MHz Triple* 6-Bit VideoDAC with L.U.T. NS
8520 Video RAM controller - 256k Bits NS
8521 Video RAM controller - 1M Bits NS
8522 Video RAM controller - 4M Bits NS
8530 Video Clock Generator (LFVCG) - 125 MHz NS
8601 TDA8601 RGB/YUV and fast blanking switch DIL16 Philips
8708 TDA8708 8 bit video ADC 32MHz Philips
8708 TDA8708B Video analog input interface DIL28 Philips
8712 TDA8712 8-bit high-performance, high-speed Video DAC DIL16 Philips
87320 UT87C320 High performance Graphic and Video Accelerator UTRON
87360 UT87C360 AGP 3D/2D Graphic and Video Accelerator UTRON
875 AL875 High speed 3-channel ADC Averlogic*
8755 TDA8755 YUV 8-bit video low-power interface Philips
8758 TDA8758 YC 8-bit low-power video interface Philips
8772 TDA8772 35/85 MHz triple* 8-bit video DAC Philips
87984 MP8798(4) CMOS* Very Low Power 1 MSPS 10-Bit Analog-to-Digital Converter with 4-Channel Mux* Exar
87998 MP8799(8) CMOS* Very Low Power Exar
88303 MP8830(3) Triple* 10-bit High Speed Analog-to-Digital Converter with Digitally Controlled References Exar
88311 MP8831(1) Single 10-Bit ADC with Digitally Controlled References Exar
88323 MP8832(3) Triple* 8-Bit High Speed ADC with Gamma Compensated References Exar
88408 MP8840(8) 8-Channel Exar
9006 CRT9006 83/135 character row buffer memory for CRT* or printer SMC
9007 CRT9007 CRT* video processor and controller SMC
9021 CRT* video attributes controller (=8321)
9021 CRT9021B Video attributes controller SMC
9028 CRT9028 Complete CRT* video processor and controller SMC
9041 CRT9041 Video attributes controller, VT-100 compatible SMC
9065 SAA9065 Video enhancement and D/A processor Philips
9100 Graphics controller Weitek*
9128 CRT9128 Complete CRT* video processor and controller SMC
9130 Power Video Accelerator Weitek*
9212 CRT9212 135 character row buffer memory for CRT* or printer SMC
9340 Graphics controller chip set with 9341 AMD
9341 Graphics controller chip set with 9340 AMD
9502 AD9502 8 bit video ADC 13MHz AD
9560 Text and graphics controller
9614 TDA9614 VHS stereo audio processor Philips
9702 AD9702 triple* 4 bit video DAC 200MHz ECL*/TTL AD
9715 TDA9715A VHS Y/C one-chip processor Philips
9725 TDA9725 VHS video (Y/C) processor DIL32SHR Philips
9768 AD9768 8 bit video DAC IO* 200MHz ECL* AD
9810 XRD9810 3-Channel 10/12-Bit Linear CCD* & CIS Sensor Signal Processors Exar
9812 XRD9812 3-Channel 10/12-Bit Linear CCD* & CIS Sensor Signal Processors Exar
9814 XRD9814 3-Channel 14/16-Bit Linear CCD*/CIS Sensor Signal Processor Exar
9815 XRD9815 3-Channel 12-Bit Linear CCD* and CIS Sensor Signal Processors Exar
9816 XRD9816 3-Channel 14/16-Bit Linear CCD*/CIS Sensor Signal Processor Exar
9820 XRD9820 3-Channel 10/12-Bit Linear CCD* & CIS Sensor Signal Processors with Analog Mux* Exar
9822 XRD9822 3-Channel 10/12-Bit Linear CCD* & CIS Sensor Signal Processors with Analog Mux* Exar
9824 XRD9824 14-Bit Linear CIS/CCD* Sensor Signal Processor with Serial Control Exar
9825 XRD9825 16-Bit Linear CIS/CCD* Sensor Signal Processor with Serial Control Exar
9826 XRD9826 16-Bit Linear CIS/CCD* Sensor Signal Processor with Serial Control Exar
9827 XRD9827 12-Bit Linear CIS/CCD* Sensor Signal Processor with Serial Control Exar
9828 XRD9828 10/12-Bit Linear CIS/CCD* Sensor Signal Processor with Parallel Interface Exar
9829 XRD9829 10-Bit Linear CIS/CCD* Sensor Signal Processor with Serial Control Exar
9853 XRD98(L)53 CCD* Image Digitizers with CDS Exar
9855 XRD98(L)55 CCD* Image Digitizers with CDS Exar
9856 XRD98(L)56 CCD* Image Digitizers with CDS Exar
9859 XRD98(L)59 CCD* Image Digitizers for High-Resolution and High-Performance Video Applications Exar
9860 XRD98L60 CCD* Image Digitizer CDS/PGA/ADC Exar
9861 XRD98L61 CCD* Image Digitizer CDS/PGA/ADC Exar
9918 WD9918 CRT* controller WD

See also

www.freetradezone.com/ Registration needed
www.icmaster.com/ Registration needed
www.itis.spb.ru/win/map_eng.htm Russian site with a lot of component overviews, large parts are in Russian
www.questlink.com/ Registration is needed before you can download datasheets

To get chips listed

When you're the webmaster/database manager of an IC* manufacturer and you'd like to get your IC*'s listed on sites like these (including the ICMaster) but don't want to deal with all sites separately, a couple of us are trying to set up a system whereby the IC* manufacturers just put a comma seperated value's (.csv) file on their site with all of their data and we all read that regurarly and work the data into our databases of chips. Please visit www.elip.org/ for more details. One of the manufacturers already cooperating is ON Semiconductor (formerly part of Motorola).

Ad for PCI video capturing boards by Dektec.
Goto: Main Mirror About Author
Register: Yourself Company
Feedback: Correction Addition Question
Order: Chips (Deutsch) Chips (English) Chips (Nederlands)

Advertisement

Viewable with any browser
